3-Piece Design

Easy to repair. In-line serviceable, swing-out center section allows easy access to internal value components without disturbing alignment of pipe

Blow Out Proof Stem

Stem is bottom loaded to prevent removal when valve is in service

ISO 5211 Direct Mounting Pad

Locking Handle

Enables plant personnel to secure valve in open or closed position when manually operated

Full Port Design

Improves flow resulting in increased process efficiencies

Investment Cast

Improves dimensional control and reduces porosity.
